Additional information
| Accessories | See Parts & Accessories Section |
|---|---|
| Certification | ANSI/BHMA A1563.3 2008 Grade 1 UL Listed (USA And Canada) |
| Design Type | Touch Bar |
| Device Type | Surface Rim |
| Dogging | Standard Dogging By Key Provided Or 5/32 Hex Wrench |
| Door Type | Commercial wood and hollow metal |
| Fire Rating | Non-Fire Rated |
| Grade | Grade 1 – Heavy Duty Commercial |
| Handing | Field Reversible |
| Industry Finish | US32D/630 Satin Stainless Steel |
| Keying Option | Outside trims use conventional mortise or rim cylinders. |
| Latch | Rim (Deadlocking latch stainless steel 3/4” throw) |
| Manufacturer | LSDA |
| Material | Stainless Steel Brass Extruded Aluminum |
| Options | Cylinder dogging option available |
| Series | PD9200 |
| Size | 48" |
| Stile Width | Minimum 2-7/8” |
| Strike | For Rim surface applied (double door strike available) |
